The Production RAG Reference Architecture
Every piece, assembled: ingestion, hybrid retrieval, re-ranking, grounded generation, guardrails, eval and caching — the blueprint you can ship.
Here is the whole system on one page — the blueprint that turns the previous nine articles into something you can deploy.
The ingestion pipeline (offline)
- Clean source docs (strip boilerplate, fix encoding).
- Chunk structurally, 300–600 tokens, ~15% overlap.
- Enrich each chunk with metadata (source, section, date, url).
- Embed with a versioned model.
- Index into Postgres/pgvector with an ANN index + a keyword index.
The query pipeline (online)
- (Optional) Rewrite the query with a small model.
- Hybrid retrieve — vector + keyword, fused with RRF, top 30–50.
- Re-rank with a cross-encoder; keep top 3–8.
- Confidence gate — if the top score is weak, return "I don't know."
- Generate grounded, with citations, from the kept chunks.
- Faithfulness check the output; cache the answer.
The loop that keeps it honest
Wrap it in evaluation + observability: run the eval set on every change (recall, faithfulness, relevance), and log real queries with their retrieval scores so you can grow the eval set from production.
That's production RAG: measurable retrieval, grounded generation, honest under uncertainty, and affordable at scale. You now have the map and the mechanics.
